Fiberglass Cloth/Tape/Rope/

E-glass Fiberglass Cloth

Alias:Fiberglass Cloth

Processing Service:Moulding, Cutting

Model Number:Support customization

Brand Name:HONGWO

Place of Origin:Hebei, China

Payment Type:T/T, L/C, PayPal, Western Union, Cash, Escrow.

Delivery Terms:FOB, CIF, EXW.

Payment Currency:USD, EUR, HKD, CNY.

Lead time (days):15~50

Delivery:By sea or by air

Packing:In wooden pallet

  • Product Details
  • Specifications
  • Prices & Lead time
  • Packing & Delivery
  • FAQ

Manufacturers use a heat-insulating, texturized fiberglass cloth with aluminum foil laminated to it. It is an excellent substitute for asbestos cloth. They weave it from E or C glass fiber texturized yarn. People use it to insulate soft or hard tubes. It also insulates heaters and coolers. Plus, it is a fire-resistant shell. It also serves as protective insulation for watercraft. Its high strength, low weight, and good insulation make it ideal for these uses.

Thickness: 0.8 mm – 3 mm

Width: 160 mm – 1500 mm Work Temperature: 350 – 700 °C

E-glass Fiberglass Cloth

E-glass Fiberglass Cloth

Parameter Description / Specification
Product Name E-glass Fiberglass Cloth/Alkali-Free Glass Fiber Cloth
Material High-purity alkali-free glass fibers
Thickness Range: 0.05mm to 1.0mm (customizable)
Width Standard: 1000mm, 1200mm (customizable widths available)
Length Standard: 30m, 50m (customizable lengths available)
Weight Range: 50g/m² to 300g/m² (depending on thickness and fiber density)
Tensile Strength Longitudinal: ≥1200 N/50mm; Transverse: ≥800 N/50mm
Elongation at Break Longitudinal: ≤3%; Transverse: ≤5%
Heat Resistance Continuous service temperature up to 450°C
Electrical Insulation Resistance ≥1×10¹² Ω
Dielectric Strength ≥20kV/mm
Flame Retardancy Complies with UL94 V-0 standards
Color White (other colors available upon request)
Weave Type Plain weave, twill weave (custom weaves available)
Surface Treatment Silicone coated, PTFE coated, or untreated (optional)
Application Printed circuit boards, electrical insulation, composites, reinforcement materials, high-temperature filtration, etc.
Packaging Rolls packed in plastic film and then in cardboard boxes or wooden crates for export
Storage Conditions Store in a dry, cool place away from direct sunlight and moisture
$2.25 / kg $2.3 / kg $1.9 / kg
200-999 kg 1000-4999 kg ≥5000 kg
Our product prices may vary by a small amount due to raw materials and the market. For the latest price, please click the link below or contact our sales staff.

Lead time: 15~20 Workdays
Payment: 30% deposite

Selling Units: Kilogram
Delivery: By sea or by air
Package Type: Packing Details:In poly bags, cartons,wooden crates or pallets standard exported package.
Picture Example:

1. Who are we?
We are based in Hebei, China, start from 1993, sell to Eastern Europe (20.00%), South America (20.00%), Southeast Asia (20.00%), Mid East (10.00%), Oceania (10.00%), Africa (10.00%), North America (10.00%). There are total about 11-50 people in our office.
2. How can we guarantee quality?
Always a pre-production sample before mass production.
Always final Inspection before shipment.
3.what can you buy from us?
Borosilicate Glass, lead glass, reflex gauge glass, transparent gauge glass.
Sealing Gaskets Sheets Series, beater paper, cylinder head gasket sheet, thermal insulation materials, braided-packing, and all kinds of sealing materials.
4. Why should you buy from us not from other suppliers?
OEM service, with our quick response. High quality control, inspection for each step. Superior after-sales service.
5. What services can we provide?
Accepted Delivery Terms: FOB, CIF, EXW.
Accepted Payment Currency: USD, EUR, HKD, CNY.
Accepted Payment Type: T/T, L/C, PayPal, Western Union, Cash, Escrow.
Language Spoken: English, Chinese, Portuguese, Russian
