Ceramic Fiber Cloth/Tape/Rope/

Ceramic Fiber Board

Alias:Ceramic Fiber Board

Processing Service:Moulding, Cutting

Model Number:Support customization

Brand Name:HONGWO

Place of Origin:Hebei, China

Payment Type:T/T, L/C, PayPal, Western Union, Cash, Escrow.

Delivery Terms:FOB, CIF, EXW.

Payment Currency:USD, EUR, HKD, CNY.

Lead time (days):15~50

Delivery:By sea or by air

Packing:In wooden pallet

  • Product Details
  • Specifications
  • Prices & Lead time
  • Packing & Delivery
  • FAQ

Ceramic fiber board uses non-brittle material, therefore it has good tenacity, high compressive strength, good flatness and mechanical process ability. Temperature is 1050℃, 1260℃, 1430℃ and it is the ideal material for wall liner and back lining of the heating equipment.

Characteristics:

Flat surface
Equal volumetric weight and thickness Excellent mechanical and structure strength Low thermal conductivity and low shrinkage

Air-current resistant washingTypical application:
Heat insulation for back lining of high temperature industrial furnace

Heat surface lining materials for porcelain furnace, heat treatment furnace of mechanical and metallurgy and other industrial furnaces.

Item
  Product
 COM ST HP HAA HZ
Specification Temp(℃) 1100 1260 1260 1360 1430
Working Tom(℃)      <1000 1050 1100 1200 1350
Color White White White White White
Density(kg/m3) 260
  320
260
  320
260
  320
260
  320
260
  320
Rate of line(%) (24h,Density:320kg/m3)  -4
  (1000℃)
 -4
  (1000℃)
 -4
  (1100℃)
 -4
  (1200℃)
-4
  (1350℃)
Rate of thermal
 Conductivity(w/m.k)
  (Density: 285kg/m3)
 0.085(400℃)
  0.132(800℃)
  0.180(1000℃)
 0.085(400℃)
  0.132(800℃)
  0.180(1000℃)
 0.085(400℃)
  0.132(800℃)
  0.180(1000℃)
 0.085(400℃)
  0.132(800℃)
  0.180(1000℃)
0.085(400℃)
  0.132(800℃)
  0.180(1000℃)
Tensile Strength (MPa)
(Strength 10%)
0.5  0.5  0.5  0.5 0.5
 Chemical composition
(%)
 Al2O3 40-44 45-46 47-49 52-55 39-40
 Al2O3+SiO2 95-96 96-97 98-99 99 -
 Al2O3+SiO2+ZrO2 - - - - 99
 ZrO2 - - - - 15-17
Fe2O3 <1.2 <1.0 0.2 0.2 0.2
 Na2O+K2O ≤0.5   ≤0.5  0.2  0.2 0.2
  Size(mm)     Common   specification: 600*400*10-5;900*600*20-50
  other made according to customer's requirements
$1.58~6.88 / kg $1.58~6.88 / kg $1.58~6.88 / kg
200-299 kg 300-999 kg ≥1000 kg
Our product prices may vary by a small amount due to raw materials and the market. For the latest price, please click the link below or contact our sales staff.

Lead time: 15~20 Workdays
Payment: 30% deposite

Selling Units: Kilogram
Delivery: By sea or by air
Package Type: Packing Details:In poly bags, cartons,wooden crates or pallets standard exported package.
Picture Example:

1. Who are we?
We are based in Hebei, China, start from 1993, sell to Eastern Europe (20.00%), South America (20.00%), Southeast Asia (20.00%), Mid East (10.00%), Oceania (10.00%), Africa (10.00%), North America (10.00%). There are total about 11-50 people in our office.
2. How can we guarantee quality?
Always a pre-production sample before mass production.
Always final Inspection before shipment.
3.what can you buy from us?
Borosilicate Glass, lead glass, reflex gauge glass, transparent gauge glass.
Sealing Gaskets Sheets Series, beater paper, cylinder head gasket sheet, thermal insulation materials, braided-packing, and all kinds of sealing materials.
4. Why should you buy from us not from other suppliers?
OEM service, with our quick response. High quality control, inspection for each step. Superior after-sales service.
5. What services can we provide?
Accepted Delivery Terms: FOB, CIF, EXW.
Accepted Payment Currency: USD, EUR, HKD, CNY.
Accepted Payment Type: T/T, L/C, PayPal, Western Union, Cash, Escrow.
Language Spoken: English, Chinese, Portuguese, Russian
